Acero 1018
121 medidas publicadas en aleación 1018. Elige la medida, ábrela en el laboratorio para verla en 3D con sus cotas o cotízala directo con VEMIK Metales.
121medidas publicadas
1aleación
12presentaciones de aceros especiales
Atención de metales · Lomas del BosqueWhatsApp 56 1087 0344Teléfonos 55 9827 3308 · 55 9827 3309 · Cedros y Eucaliptos 7, Cuautitlán Izcalli · L–V 8:30–19:00, S y D 9:30–18:00
Sucursal AtizapánSolo ferreteríaAtizapán no atiende metales: toda cotización y recolección de metal es con Lomas del Bosque.WhatsApp ferretería 56 1748 8633 ↗
Tabla técnica
Medidas de acero 1018
| Aleación | Diámetro mm | Pulgadas | Decimal | Largo m | Peso kg/m | Alto mm | Alto pulg. | Ancho mm | Ancho pulg. | Acciones |
|---|---|---|---|---|---|---|---|---|---|---|
| 1018 | 3.2 | 1/8 | 0.125 | 3.05 - 3.66 | 0.06 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 0.1875 | 3.66 | 0.18 | 4.8 | 3/16 | 4.8 | 3/16 | Cotizar3D |
| 1018 | — | — | 0.25 | 3.05–3.66 | 0.16 | 3.2 | 1/8 | 6.4 | 1/4 | Cotizar3D |
| 1018 | 4.8 | 3/16 | 0.187 | 3.05 - 3.66 | 0.14 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 0.25 | 3.66 | 0.33 | 6.4 | 1/4 | 6.4 | 1/4 | Cotizar3D |
| 1018 | — | — | 0.5 | 3.05–3.66 | 0.33 | 3.2 | 1/8 | 12.7 | 1/2 | Cotizar3D |
| 1018 | 6.4 | 1/4 | 0.25 | 3.05 - 3.66 | 0.25 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 0.3125 | 3.66 | 0.51 | 7.9 | 5/16 | 7.9 | 5/16 | Cotizar3D |
| 1018 | — | — | 1 | 3.05–3.66 | 0.66 | 3.2 | 1/8 | 25.4 | 1 | Cotizar3D |
| 1018 | 7.9 | 5/16 | 0.312 | 3.05 - 3.66 | 0.39 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 0.375 | 3.66 | 0.74 | 9.5 | 3/8 | 9.5 | 3/8 | Cotizar3D |
| 1018 | — | — | 0.5 | 3.05–3.66 | 0.49 | 4.8 | 3/16 | 12.7 | 1/2 | Cotizar3D |
| 1018 | 9.5 | 3/8 | 0.375 | 3.05 - 3.66 | 0.56 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 0.5 | 3.66 | 1.32 | 12.7 | 1/2 | 12.7 | 1/2 | Cotizar3D |
| 1018 | — | — | 1 | 3.05–3.66 | 0.99 | 4.8 | 3/16 | 25.4 | 1 | Cotizar3D |
| 1018 | 11.1 | 7/16 | 0.437 | 3.05 - 3.66 | 0.77 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 0.5625 | 3.66 | 1.68 | 14.3 | 9/16 | 14.3 | 9/16 | Cotizar3D |
| 1018 | — | — | 1.25 | 3.05–3.66 | 1.24 | 4.8 | 3/16 | 31.8 | 1 1/4 | Cotizar3D |
| 1018 | 12.7 | 1/2 | 0.5 | 3.05 - 3.66 | 1.01 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 0.625 | 3.66 | 2.07 | 15.9 | 5/8 | 15.9 | 5/8 | Cotizar3D |
| 1018 | — | — | 1.5 | 3.05–3.66 | 1.49 | 4.8 | 3/16 | 38.1 | 1 1/2 | Cotizar3D |
| 1018 | 14.3 | 9/16 | 0.562 | 3.05 - 3.66 | 1.28 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 0.75 | 3.66 | 2.98 | 19.1 | 3/4 | 19.1 | 3/4 | Cotizar3D |
| 1018 | — | — | 2 | 3.05–3.66 | 1.99 | 4.8 | 3/16 | 50.8 | 2 | Cotizar3D |
| 1018 | 15.9 | 5/8 | 0.625 | 3.05 - 3.66 | 1.58 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 0.875 | 3.66 | 4.06 | 22.2 | 7/8 | 22.2 | 7/8 | Cotizar3D |
| 1018 | — | — | 2.5 | 3.05–3.66 | 2.49 | 4.8 | 3/16 | 63.5 | 2 1/2 | Cotizar3D |
| 1018 | 17.5 | 11/16 | 0.687 | 3.05 - 3.66 | 1.91 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 1 | 3.66 | 5.31 | 25.4 | 1 | 25.4 | 1 | Cotizar3D |
| 1018 | — | — | 3 | 3.05–3.66 | 2.98 | 4.8 | 3/16 | 76.2 | 3 | Cotizar3D |
| 1018 | 19.1 | 3/4 | 0.75 | 3.05 - 3.66 | 2.27 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 1.125 | 3.66 | 6.72 | 28.6 | 1 1/8 | 28.6 | 1 1/8 | Cotizar3D |
| 1018 | — | — | 4 | 3.05–3.66 | 3.98 | 4.8 | 3/16 | 101.6 | 4 | Cotizar3D |
| 1018 | 20.6 | 13/16 | 0.812 | 3.05 - 3.66 | 2.67 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 1.25 | 3.66 | 8.30 | 31.8 | 1 1/4 | 31.8 | 1 1/4 | Cotizar3D |
| 1018 | — | — | 0.375 | 3.05–3.66 | 0.49 | 6.4 | 1/4 | 9.5 | 3/8 | Cotizar3D |
| 1018 | 22.2 | 7/8 | 0.875 | 3.05 - 3.66 | 3.10 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 1.5 | 3.66 | 11.95 | 38.1 | 1 1/2 | 38.1 | 1 1/2 | Cotizar3D |
| 1018 | — | — | 1 | 3.05–3.66 | 1.32 | 6.4 | 1/4 | 25.4 | 1 | Cotizar3D |
| 1018 | 23.8 | 15/16 | 0.937 | 3.05 - 3.66 | 3.55 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 1.75 | 3.66 | 16.27 | 44.5 | 1 3/4 | 44.5 | 1 3/4 | Cotizar3D |
| 1018 | — | — | 1.5 | 3.05–3.66 | 1.99 | 6.4 | 1/4 | 38.1 | 1 1/2 | Cotizar3D |
| 1018 | 25.4 | 1 | 1 | 3.05 - 3.66 | 4.05 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 2 | 3.66 | 21.25 | 50.8 | 2 | 50.8 | 2 | Cotizar3D |
| 1018 | — | — | 1.75 | 3.05–3.66 | 2.32 | 6.4 | 1/4 | 44.5 | 1 3/4 | Cotizar3D |
| 1018 | 27 | 1 1/16 | 1.062 | 3.05 - 3.66 | 4.57 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 2.25 | 3.66 | 26.90 | 57.2 | 2 1/4 | 57.2 | 2 1/4 | Cotizar3D |
| 1018 | — | — | 2 | 3.05–3.66 | 2.65 | 6.4 | 1/4 | 50.8 | 2 | Cotizar3D |
| 1018 | 28.6 | 1 1/8 | 1.125 | 3.05 - 3.66 | 5.12 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 2.5 | 3.66 | 33.21 | 63.5 | 2 1/2 | 63.5 | 2 1/2 | Cotizar3D |
| 1018 | — | — | 2.5 | 3.05–3.66 | 3.32 | 6.4 | 1/4 | 63.5 | 2 1/2 | Cotizar3D |
| 1018 | 30.2 | 1 3/16 | 1.187 | 3.05 - 3.66 | 5.71 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 3 | 3.66 | 47.83 | 76.2 | 3 | 76.2 | 3 | Cotizar3D |
| 1018 | — | — | 3 | 3.05–3.66 | 3.98 | 6.4 | 1/4 | 76.2 | 3 | Cotizar3D |
| 1018 | 31.8 | 1 1/4 | 1.25 | 3.05 - 3.66 | 6.32 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 3.5 | 3.66 | 65.10 | 88.9 | 3 1/2 | 88.9 | 3 1/2 | Cotizar3D |
| 1018 | — | — | 5 | 3.05–3.66 | 6.64 | 6.4 | 1/4 | 127 | 5 | Cotizar3D |
| 1018 | 33.3 | 1 5/16 | 1.312 | 3.05 - 3.66 | 6.97 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 5 | 3.66 | 132.87 | 127 | 5 | 127 | 5 | Cotizar3D |
| 1018 | — | — | 6 | 3.05–3.66 | 7.97 | 6.4 | 1/4 | 152.4 | 6 | Cotizar3D |
| 1018 | 34.9 | 1 3/8 | 1.375 | 3.05 - 3.66 | 7.65 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 6 | 3.66 | 191.33 | 152.4 | 6 | 152.4 | 6 | Cotizar3D |
| 1018 | — | — | 8 | 3.05–3.66 | 10.62 | 6.4 | 1/4 | 203.2 | 8 | Cotizar3D |
| 1018 | 36.5 | 1 7/16 | 1.437 | 3.05 - 3.66 | 8.36 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 0.5 | 3.05–3.66 | 0.83 | 7.9 | 5/16 | 12.7 | 1/2 | Cotizar3D |
| 1018 | 38.1 | 1 1/2 | 1.5 | 3.05 - 3.66 | 9.11 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 1 | 3.05–3.66 | 1.66 | 7.9 | 5/16 | 25.4 | 1 | Cotizar3D |
| 1018 | 41.3 | 1 5/8 | 1.625 | 3.05 - 3.66 | 10.69 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 2 | 3.05–3.66 | 3.32 | 7.9 | 5/16 | 50.8 | 2 | Cotizar3D |
| 1018 | 44.5 | 1 3/4 | 1.75 | 3.05 - 3.66 | 12.40 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 3 | 3.05–3.66 | 4.98 | 7.9 | 5/16 | 76.2 | 3 | Cotizar3D |
| 1018 | 47.6 | 1 7/8 | 1.875 | 3.05 - 3.66 | 14.23 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 4 | 3.05–3.66 | 6.64 | 7.9 | 5/16 | 101.6 | 4 | Cotizar3D |
| 1018 | 49.2 | 1 15/16 | 1.937 | 3.05 - 3.66 | 15.20 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 6 | 3.05–3.66 | 9.96 | 7.9 | 5/16 | 152.4 | 6 | Cotizar3D |
| 1018 | 50.8 | 2 | 2 | 3.05 - 3.66 | 16.2 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 0.5 | 3.05–3.66 | 0.99 | 9.5 | 3/8 | 12.7 | 1/2 | Cotizar3D |
| 1018 | 52.4 | 2 1/16 | 2.062 | 3.05 - 3.66 | 17.22 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 0.625 | 3.05–3.66 | 1.24 | 9.5 | 3/8 | 15.9 | 5/8 | Cotizar3D |
| 1018 | 54 | 2 1/8 | 2.125 | 3.05 - 3.66 | 18.28 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 0.75 | 3.05–3.66 | 1.49 | 9.5 | 3/8 | 19.1 | 3/4 | Cotizar3D |
| 1018 | 55.6 | 2 3/16 | 2.187 | 3.05 - 3.66 | 19.37 | — | — | — | — | Cotizar3D |
| 1018 | — | — | 1 | 3.05–3.66 | 1.99 | 9.5 | 3/8 | 25.4 | 1 | Cotizar3D |
| 1018 | 57.2 | 2 1/4 | 2.25 | 3.05 - 3.66 | 20.50 | — | — | — | — | Cotizar3D |
| 1018 | 60.3 | 2 3/8 | 2.375 | 3.05 - 3.66 | 22.84 | — | — | — | — | Cotizar3D |
| 1018 | 61.9 | 2 7/16 | 2.437 | 3.05 - 3.66 | 24.06 | — | — | — | — | Cotizar3D |
| 1018 | 63.5 | 2 1/2 | 2.5 | 3.05 - 3.66 | 25.31 | — | — | — | — | Cotizar3D |
| 1018 | 69.9 | 2 3/4 | 2.75 | 3.05 - 3.66 | 30.62 | — | — | — | — | Cotizar3D |
| 1018 | 76.2 | 3 | 3 | 3.05 - 3.66 | 36.45 | — | — | — | — | Cotizar3D |
| 1018 | 82.6 | 3 1/4 | 3.25 | 3.05 - 3.66 | 42.77 | — | — | — | — | Cotizar3D |
| 1018 | 88.9 | 3 1/2 | 3.5 | 3.05 - 3.66 | 49.61 | — | — | — | — | Cotizar3D |
| 1018 | 95.3 | 3 3/4 | 3.75 | 3.05 - 3.66 | 56.95 | — | — | — | — | Cotizar3D |
| 1018 | 101.6 | 4 | 4 | 3.05 - 3.66 | 64.8 | — | — | — | — | Cotizar3D |
| 1018 | 114.3 | 4 1/2 | 4.5 | 3.05 - 3.66 | 82.01 | — | — | — | — | Cotizar3D |
| 1018 | 114.3 | 4 1/2 | 4.5 | 3.05 - 3.66 | 82.01 | — | — | — | — | Cotizar3D |
| 1018 | 120.6 | 4 3/4 | 4.75 | 3.05 - 3.66 | 91.37 | — | — | — | — | Cotizar3D |
| 1018 | 127 | 5 | 5 | 3.05 - 3.66 | 101.25 | — | — | — | — | Cotizar3D |
| 1018 | 133.3 | 5 1/4 | 5.25 | 3.05 - 3.66 | 111.62 | — | — | — | — | Cotizar3D |
| 1018 | 139.7 | 5 1/2 | 5.5 | 3.05 - 3.66 | 122.51 | — | — | — | — | Cotizar3D |
| 1018 | 146 | 5 3/4 | 5.75 | 3.05 - 3.66 | 133.90 | — | — | — | — | Cotizar3D |
| 1018 | 152.4 | 6 | 6 | 3.05 - 3.66 | 145.8 | — | — | — | — | Cotizar3D |
| 1018 | 165.1 | 6 1/2 | 6.5 | 3.05 - 3.66 | 171.11 | — | — | — | — | Cotizar3D |
| 1018 | 177.8 | 7 | 7 | 3.05 - 3.66 | 198.45 | — | — | — | — | Cotizar3D |
| 1018 | 190.5 | 7 1/2 | 7.5 | 3.05 - 3.66 | 227.81 | — | — | — | — | Cotizar3D |
| 1018 | 203.2 | 8 | 8 | 3.05 - 3.66 | 259.2 | — | — | — | — | Cotizar3D |
| 1018 | 215.9 | 8 1/2 | 8.5 | 3.05 - 3.66 | 292.61 | — | — | — | — | Cotizar3D |
| 1018 | 228.6 | 9 | 9 | 3.05 - 3.66 | 328.05 | — | — | — | — | Cotizar3D |
| 1018 | 241.3 | 9 1/2 | 9.5 | 3.05 - 3.66 | 365.51 | — | — | — | — | Cotizar3D |
| 1018 | 254 | 10 | 10 | 3.05 - 3.66 | 405 | — | — | — | — | Cotizar3D |
| 1018 | 266.7 | 10 1/2 | 10.5 | 3.05 - 3.66 | 446.51 | — | — | — | — | Cotizar3D |
| 1018 | 279.4 | 11 | 11 | 3.05 - 3.66 | 490.05 | — | — | — | — | Cotizar3D |
| 1018 | 292.1 | 11 1/2 | 11.5 | 3.05 - 3.66 | 535.61 | — | — | — | — | Cotizar3D |
| 1018 | 304.8 | 12 | 12 | 3.05 - 3.66 | 583.2 | — | — | — | — | Cotizar3D |
| 1018 | 330.2 | 13 | 13 | 3.05 - 3.66 | 684.45 | — | — | — | — | Cotizar3D |
| 1018 | 355.6 | 14 | 14 | 3.05 - 3.66 | 793.8 | — | — | — | — | Cotizar3D |
| 1018 | 381 | 15 | 15 | 3.05 - 3.66 | 911.25 | — | — | — | — | Cotizar3D |
| 1018 | 406.4 | 16 | 16 | 3.05 - 3.66 | 1036.8 | — | — | — | — | Cotizar3D |
| 1018 | 431.8 | 17 | 17 | 3.05 - 3.66 | 1170.45 | — | — | — | — | Cotizar3D |
| 1018 | 457.2 | 18 | 18 | 3.05 - 3.66 | 1312.2 | — | — | — | — | Cotizar3D |
| 1018 | 482.6 | 19 | 19 | 3.05 - 3.66 | 1462.05 | — | — | — | — | Cotizar3D |
| 1018 | 508 | 20 | 20 | 3.05 - 3.66 | 1620 | — | — | — | — | Cotizar3D |
121 medidas
Medidas y pesos de referencia publicados por VEMIK Metales. Precio, existencia, largo disponible, corte y entrega se confirman con un asesor antes de cualquier compromiso.
Cómo cotizar
Tres datos y te respondemos.
- Elige la medidaBusca en la tabla por medida, pulgada o aleación.
- Indica largo y cantidadPieza completa o corte: el corte y su tolerancia se confirman con el asesor.
- Envía tu solicitudPor WhatsApp a VEMIK Metales. Precio, existencia y entrega se confirman antes de cualquier compromiso.
Laboratorio de medidas
Abrir el laboratorio →Míralo en 3D antes de pedirlo.
Elige la medida, define el largo o el corte y agrégalo a tu nota junto con lo que necesites de ferretería.
